From LALR to IELR: A Lrama's Next Step

RubyKaigi 2024 day 3
https://rubykaigi.org/2024/presentations/junk0612.html

References:
Lrama Repository: https://github.com/ruby/lrama
Yuichiro Kaneko, "The future vision of Ruby parser", May 2023: https://youtu.be/IhfDsLx784g?si=kO1q6mLpTa1bIRYL
Yuichiro Kaneko, "Ruby Parser開発日誌(14) - LR parser完全に理解した", Dec 2023: https://yui-knk.hatenablog.com/entry/2023/12/06/082203
Junichi Kobayashi, "Lrama へのコントリビューションを通して学ぶ Ruby のパーサジェネレータ事情", Sep 2023: https://speakerdeck.com/junk0612/lrama-henokontoribiyusiyonwotong-sitexue-bu-ruby-nopasazieneretashi-qing
Junichi Kobayashi, "Understanding Parser Generator surrounding Ruby with Contributing Lrama", Dec 2023: https://speakerdeck.com/junk0612/understanding-parser-generators-surrounding-ruby-with-contributing-lrama
Ruby 3.3.0 Release Note: https://www.ruby-lang.org/en/news/2023/12/25/ruby-3-3-0-released/
Yuichiro Kaneko, Ruby Parser Roadmap: https://docs.google.com/presentation/d/1E4v9WPHBLjtvkN7QqulHPGJzKkwIweVfcaMsIQ984_Q/edit?usp=sharing
Joel E. Denny, "PSLR(1): Pseudo-Scannerless Minimal LR(1) for the Deterministic Parsing of Composite Languages", May 2010: https://tigerprints.clemson.edu/all_dissertations/519/
Joel E. Denny and Brian A. Malloy, "The IELR(1) algorithm for generating minimal LR(1) parser tables for non-LR(1) grammars with conflict resolution" https://www.sciencedirect.com/science/article/pii/S0167642309001191

Transcript

1. From LALR to IELR: A Lrama's Next Step Junichi Kobayashi (@junk0612) ESM, Inc. RubyKaigi 2024 Naha Cultural Arts Theater NAHArt 2024/05/17(Fri.)
2. Junichi Kobayashi • X / GitHub: @junk0612 • Working at ESM, Inc. ◦ Work as a Rails engineer ◦ A Member of Parser Club • Hobbies ◦ Parsers ◦ Rhythm games, Board games ◦ Haiku
3. Contributor of Lrama
4. Contributor of Lrama • Became in Official Party !!! Committer
5. Night Cruise Sponsor
6. Night Cruise Sponsor
7. Attendees from ESM Attendee @kasumi8pon Attendee @mhirata Attendee @sfjwr Karaoke @fugakkbn Speaker @koic Attendee @wai-doi Speaker @junk0612 Attendee @haruguchi Attendee @htkymtks @S.H. LT
8. Overview of Lrama おきなさい。おきなさい　わたしの　かわいい　ぼうや ……。 きょうは　とても　たいせつなひ。あなたが　はじめて おしろに　いくひ　だったでしょう。 ―勇者の母親
9. Lrama • A LALR parser generator built with Ruby ◦ https://github.com/ruby/lrama • Presented in RubyKaigi 2023 by Yuichiro Kaneko ◦ https://youtu.be/IhfDsLx784g?si=kO1q6mLpTa1bIRYL • Use in CRuby 3.3 build process ◦ Use BASERUBY when building Ruby
10. Basis of LR Parser https://yui-knk.hatenablog.com/entry/2023/12/06/082203
11. My Contributions to Lrama Slide(JP, presented in Osaka RubyKaigi 03): https://speakerdeck.com/junk0612/lrama-henokontoribiyusiyonwotong-sitexu e-bu-ruby-nopasazieneretashi-qing Slide(EN, presented in RubyConf Taiwan 2023): https://speakerdeck.com/junk0612/understanding-parser-generators-surroun ding-ruby-with-contributing-lrama
12. My Contributions to Lrama https://www.ruby-lang.org/en/news/2023/12/25/ruby-3-3 -0-released/
13. What We Aim to Solve おお　えにくす！　ゆうしゃロトの　ちをひくものよ！ そなたのくるのをまっておったぞ。 ―ラルス16世
14. What We Aim to Solve • Hard to manage the CRuby's lexer state
15. A Motivating Example $ ruby -e 'p 1.. || 2' #=> ???
16. $ ruby -e 'p 1.. || 2' -e:1: syntax error, unexpected '|' p 1.. || 2 -e: compile error (SyntaxError) A Motivating Example
17. $ ruby -e 'p 1.. || 2' -e:1: syntax error, unexpected '|' p 1.. || 2 -e: compile error (SyntaxError) A Motivating Example
18. Exec with Parser Info
19. $ ruby -y -e 'p 1.. || 2' | rg 'Next token' | uniq Next token is token "local variable or method" (1.0-1.1: p) Next token is token "integer literal" (1.2-1.3: 1) Next token is token ".." (1.3-1.5: ) Next token is token '|' (1.6-1.7: ) Next token is token '|' (1.7-1.8: ) Scanned Tokens
20. case '|': if ((c = nextc(p)) == '|') { (...snip...) if (IS_lex_state_for(last_state, EXPR_BEG)) { c = '|'; pushback(p, '|'); return c; } return tOROP; } yylex in parse.y
21. $ ruby -y -e 'p 1.. || 2' | rg 'Next token|lex_state' | uniq lex_state: NONE -> BEG at line 2195 lex_state: BEG -> CMDARG at line 10384 Next token is token "local variable or method" (1.0-1.1: p) lex_state: CMDARG -> END at line 9649 lex_state: END -> END at line 8930 Next token is token "integer literal" (1.2-1.3: 1) lex_state: END -> BEG at line 10872 Next token is token ".." (1.3-1.5: ) lex_state: BEG -> BEG at line 10789 Next token is token '|' (1.6-1.7: ) lex_state: BEG -> BEG|LABEL at line 10808 Next token is token '|' (1.7-1.8: ) lex_state
22. $ ruby -y -e 'p 1.. || 2' | rg 'Next token|lex_state' | uniq lex_state: NONE -> BEG at line 2195 lex_state: BEG -> CMDARG at line 10384 Next token is token "local variable or method" (1.0-1.1: p) lex_state: CMDARG -> END at line 9649 lex_state: END -> END at line 8930 Next token is token "integer literal" (1.2-1.3: 1) lex_state: END -> BEG at line 10872 Next token is token ".." (1.3-1.5: ) lex_state: BEG -> BEG at line 10789 Next token is token '|' (1.6-1.7: ) lex_state: BEG -> BEG|LABEL at line 10808 Next token is token '|' (1.7-1.8: ) lex_state
23. Problems of Changing Lexer • Hard to identify the scope of impact of the change ◦ parse.y is over 16k LOC ◦ lex_state is not the only variable that determines lexer behavior
24. Problems of Changing Lexer • Change cost for future maintenance will almost certainly increase ◦ parse.y is always the most readable now ◦ (Lrama tries to decrease these cost)
25. Parser and Lexer • Academically, parser and lexer are considered separable • In reality, however, the state of the lexer is affected by the state of the parser ◦ The same sequence of symbols can have different meanings depending on where they are written, and the tokens you want to cut out are different
26. • || ◦ a || b -> '||' ◦ ary.each {|| do_something } -> '|' '|' • <<- ◦ p <<-HEREDOC -> '<<-' ◦ [] <<-1 -> '<<' '-' • %s{a} ◦ p %s{a} -> '%s{' 'a' '}' ◦ 1 %s{a} -> '%' 's' '{' 'a' '}' Examples
27. Scannerless Parser やっぱり修行で得た力と言うのは　他人のために使うものだと私 は思います。 ―アバン
28. Ruby Parser Roadmap https://docs.google.com/presentation/d/1E4v9WPHBLjtvkN7QqulHPGJzKkwIweVfcaMsIQ984_Q/edit?usp=sharing
29. Scannerless Parser • Performs tokenization and parsing in a single step • Infer acceptable tokens for each states from the grammar file ◦ Lexer state management is done by the computer, not the developer Scannerless Parser Lexer Parser
30. PSLR • Pseudo-scannerless Minimal LR • https://tigerprints.clemson.edu/all_dissertations/519/ • Tokenize only tokens that are acceptable in the current context by pseudo lexer
31. Ruby Parser Roadmap https://docs.google.com/presentation/d/1E4v9WPHBLjtvkN7QqulHPGJzKkwIweVfcaMsIQ984_Q/edit?usp=sharing
32. PSLR • LALR has insufficient parsing capabilities for the parser part of PSLR • It requires a LR algorithm with the same parsing capability as Canonical LR • There is a difference in parsable grammar between Canonical LR and LALR
33. Canonical LR • Perform a reduction on a rule when the next token is included by the lookahead set • Widest range of languages that can be parsed by the LR method • Huge number of states are created • Large space complexity required
34. LALR (LookAhead LR) • Merge states with a same core from the Canonical LR automaton • Slightly less languages can be parsed than Canonical LR • Compared to Canonical LR, merging the states may cause some conflicts ◦ These are called "Mysterious Conflicts" in the document of GNU Bison
35. IELR Overview そして　えにくす。どんなに　はなれていても オレたちは　友だちだよな！ ―キーファ
36. IELR • Inadequacy Elimination LR • https://www.sciencedirect.com/science/article/pii/S01676423 09001191 • As a part of preliminary works of the PSLR paper • Bridging the gap between LALR and Canonical LR while taking advantage of LALR's strengths of small space complexities
37. IELR Concepts • Create a parser table for LALR • Recompute the lookahead sets for each states from the start state • Verify that the state merge did not cause any Mysterious Conflicts using the original lookahead set and the recomputed lookahead set
38. Implement IELR parser だから 頼んだぜ 勇者さま。オレにも見せてくれよな。 魔王をぶっ倒す 勇者の奇跡ってヤツをさ。 ―カミュ
39. IELR Implementation in Lrama def split_states (...snip...) transition_queue = [] @states.first.transitions.each do |shift, next_state| transition_queue << [@states.first, shift, next_state] end until transition_queue.empty? state, shift, next_state = transition_queue.shift compute_state(state, shift, next_state) next_state.transitions.each do |sh, next_st| transition_queue << [next_state, sh, next_st] end end end
40. def compute_state(state, shift, next_state) k = propagate_lookaheads(state, next_state) s = @ielr_isocores[next_state].find {|st| compatible?(st, k) } if s.nil? split_state(@ielr_isocores[next_state].last) elsif(!@lookaheads_recomputed[s]) @item_lookahead_set[s] = k @lookaheads_recomputed[s] = true else state.update_transition(shift, s) merge_lookaheads(s, k) end end IELR Implementation in Lrama
41. https://github.com/ruby/lrama/pull/398 Pull Request
42. Conclusion 人の　愛は　勇気は　消して　消えることは　ありません もし　私が闇に墜ちてしまったら その時は　どうか　この剣を手に …… ―聖竜
43. Conclusion • Managing lex_state is difficult • Solve it to support PSLR parser generation to Lrama • Implement IELR that is the prerequisite of PSLR • IELR is bridging the gap of the parse capability between LALR and Canonical LR
44. Future Works • Merge the PR • Support generating PSLR parsers • Refactor parse.y and throw lex_state away
45. Acknowledgements • @yui-knk, @ydah ◦ #lramafriends #LR_parser_gangs • @koic, @S.H. ◦ #esm_parser_club • My Wife ◦ #a_beautiful_life
46. References • Lrama Repository: https://github.com/ruby/lrama • Yuichiro Kaneko, "The future vision of Ruby parser", May 2023: https://youtu.be/IhfDsLx784g?si=kO1q6mLpTa1bIRYL • Yuichiro Kaneko, "Ruby Parser開発日誌(14) - LR parser完全に理解した", Dec 2023: https://yui-knk.hatenablog.com/entry/2023/12/06/082203 • Junichi Kobayashi, "Lrama へのコントリビューションを通して学ぶ Ruby のパーサ ジェネレータ事情", Sep 2023: https://speakerdeck.com/junk0612/lrama-henokontoribiyusiyonwotong-si texue-bu-ruby-nopasazieneretashi-qing
47. References • Junichi Kobayashi, "Understanding Parser Generator surrounding Ruby with Contributing Lrama", Dec 2023: https://speakerdeck.com/junk0612/understanding-parser-generators-surr ounding-ruby-with-contributing-lrama • Ruby 3.3.0 Release Note: https://www.ruby-lang.org/en/news/2023/12/25/ruby-3-3-0-released/ • Yuichiro Kaneko, Ruby Parser Roadmap: https://docs.google.com/presentation/d/1E4v9WPHBLjtvkN7QqulHPGJzKk wIweVfcaMsIQ984_Q/edit?usp=sharing
48. References • Joel E. Denny, "PSLR(1): Pseudo-Scannerless Minimal LR(1) for the Deterministic Parsing of Composite Languages", May 2010: https://tigerprints.clemson.edu/all_dissertations/519/ • Joel E. Denny and Brian A. Malloy, "The IELR(1) algorithm for generating minimal LR(1) parser tables for non-LR(1) grammars with conflict resolution" https://www.sciencedirect.com/science/article/pii/S0167642309001191
49. Presentations around Parsers
50. Presentations around Parsers
51. That's one small patch for Lrama, one giant leap for Ruby.
